myOSLchip is a handheld OSL reader which can be used to read and *erase its compatible dosimeters (myOSLchip dosimeter). The myOSLchip is equipped with a touch display which allows autonomously measurements without PC connection.
Measurement data can be stored on a USB stick. Internal Data Matrix scanner
identifies the individual number of the myOSLchip dosimeters.
The dosimeters can be used for patient dosimetry, QC of radiation therapy
treatments, research,…



Technical Specifications myOSLchip reader
OSL stimulation Blue light – 480nm
Erasing unit bleaching LED for low doses
User interface Mini USB or Ethernet
Dimension ca. 23.5cm x 14.6cm x 9cm
Weight ca. 5 kg
Voltage individual barcode
Dimension (without Blister) 100-240 VDC 50/60 Hz
(external power supply)
Technical Specifications myOSLchip dosimeter
OSL material BeO (removable for annealing)
Dose range 0.05mGy – 10Gy
Dose linearity up to 10Gy
Energy response 16keV to several MeV
Identification individual Data Matrix Code and
readable number
Dimension ca. 0.95cm x 1.00 cm x 0.20cm
Weight ca. 0.2 gram
